ST52 ASTM A53 Square Galvanized Steel Pipes Small Diameter For Glass Curtain Wall

Large Image : ST52 ASTM A53 Square Galvanized Steel Pipes Small Diameter For Glass Curtain Wall Get Best Price

Product Details:

Place of Origin:	Tianjin China
Brand Name:	XQS
Certification:	ISO9001,BV,SGS,CE,API
Model Number:	SHDGI 26

Payment & Shipping Terms:

Minimum Order Quantity:	5Ton/Tons/MT or according customers’ requirements
Price:	Negotiable
Packaging Details:	1.By bulk(Big O.D) 2.By steel strips packed into bundles(Small O.D) 3.Waterproof Package
Delivery Time:	15-20 days after receiving 30%T/T Deposit or L/C At Sight.
Payment Terms:	T/T, L/C At Sight, Western Union,D/A,D/P, Money Gram
Supply Ability:	400,000 Ton per year

Contact Now

Detailed Product Description

High Light:

mild steel tube

structural steel pipes

ST52 ASTM A53 Square Galvanized Steel Pipes Small Diameter For Glass Curtain Wall

Detail:

SHS Galvanized Steel Pipe/Tube

Square Welded Galvanized Steel Piping / Tubing

Square Hot Rolled Galvanized Steel Pipes

Outer Diameter /O.D/mm	20mm20mm - 500mm500mm	Wall Thickness /W.T/mm	1.0-17.75	Section Shape	Square
Grade	Q195-Q345/S235/S275/S355/16Mn/20#/45#,/20MN2/SS41/A36/A35/ ST37/ST35
Standard	ASTM A53, API5L GR.B, DIN2440,GB,BS3604, DIN EN10219	Zinc Coated/(g/m2)	20-350	Special Pipe	Thick Wall Pipe
Type	Welded	Welded Line Type	Longitudinal	Alloy Or Not	Non-alloy
Secondary Or Not	Non-secondary

Specifications:

We are the manufacturer of steel pipe/tube and steel coils. Supply high quality various sizes products,

the cheapest price and the best service for you. The list size we often produce for your reference.

We also always have the huge ready stock for sell.

Commodity	ST52 , ASTM A53 SHS Galvanized Steel Pipes / Small Diameter SHS Welded GI Tubes For Glass Curtain Wall
Specification/mm	W.T/mm	Length/m
20*20	1.0,1.3,1.4,1.5,1.7,2.0	5.8 -11.8 or according the customers’ requirement
25*25	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-3.0
30*30	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-3.0
40*40	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-6.0
50*50	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-6.0
60*60	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-6.0
70*70	1.3,1.4,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-6.0
75*75	1.3,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-5.75
80*80	1.3,1.5,1.7,1.8,2.0,2.2,2.5-4.0,4.25-5.0,5.25-5.75
100*100	1.5,1.7,1.8,2.0,2.2,2.5-5.0,5.25-6.0,6.5-7.75,9.5-13
120*120	2.5-2.75,3.0-4.0,4.25-6.0,6.5-7.75,9.5-15
130*130	2.5-2.75,3.0-4.0,4.25-6.0,6.25-7.75,9.5-15
135*135	2.5-2.75,3.0-4.0,4.25-6.0,6.25-7.75,9.5-15
140*140	2.5-2.75,3.0-4.0,4.25-6.0,6.25-7.75,9.5-15
150*150	2.5-2.75,3.0-4.0,4.25-6.0,6.25-7.75,9.5-15
160*160	2.5-3.75,4.5-5.0,5.25-7.75,9.5-15
180*180	2.5-3.75,4.5-5.0,5.25-7.75,9.5-15
200*200	3.0-3.25,3.5-5.75,7.5-7.75,9.5-12.5,12.75-15.75
250*250	4.5-5.75,7.5-11.75,12.5-14.75,15.5-17.75
300*300	4.75-5.75,9.5-11.75,12.5-14.75,15.5-17.75
350*350	4.75-5.75,9.5-11.75,12.5-14.75,15.5-17.75
400*400	4.5-5.75,7.5-11.75,12.5-13.75,14.5-14.75,15.5-17.75
450*450	4.5-5.75,7.5-7.75,9.5-9.75,11.5-13.75,14.5-15.75,16.5-17.75
500*500	4.5-5.75,7.5-7.75,9.5-9.75,11.5-13.75,14.5-15.75,16.5-17.75
Material	Q195-Q235B,Q195,Q195L,Q235,Q345B,Q345D,ST37, ST35, A36, A53,SS41 20#,45#,20MN2,SS400
Zinc Coated /(g/m2)	20-350
Surface Treatment	1.Galvanized 2.Others Varnish painted on pipe (black painting), anticorrosion oil and insulation treatment, or painting as customer's request.
End Treatment	Plain/Beveled/Thread with Sockets/Flange/Coupling and Plastic
Inspection	Hydraulic testing, Eddy current, Infrared test.
Package	1.Packed by Steel strips.(Small O.D) 2.Water-proof Cloth Covered with Tarpaulin. 3.In Bulk(Big O.D) 4.According to Customers’ Requirements.
Lead Time	15-20 days after receiving 30%T/T Deposit or L/C At Sight.
Price	Get the latest Price
Payment Term	T/T L/C at sight Western Union
Trade Term	FOB , CIF, CFR, EXW
MOQ	20 Ton/Tons
Supply Ability	400,000T per year
Application	SHS Galvanized Steel Pipe/Tube is mainly used in engineering construction, glass curtain wall, door and window decoration, steel structure, guardrail, machinery manufacturing,automobile manufacturing,household appliances manufacturing, shipbuilding,container manufacturing, electricity, agriculture, agricultural greenhouse, bicycle,motorcycle frame, shelves, fitness equipment, leisure and tourism products,steel furniture, a variety of specifications oil casing tubing , water,gas, sewage, air, steam heating and other fluid transport, fire and the bracket, mine air pressure, drainage, drainage gas and slurry transportation, the construction industry and other fields.
Remark	The materials of these specifications are Q195 - Q235,Q195L material and Q345B,Q345C,Q345D material can be customized according customers’ requirements, the price for these customized specifications is negotiable. We can supply any custom dimension, specification and other international standards to fit your needs. Help you to control the cost to maximize the profit. Hope to cooperate with you in the early future.
