Electrical Small Mobile Air Conditioning White Cooling Heating 220V 9000 BTU

Model

8000BTU

Power supply

Ph-V-Hz

220-240V~ 50Hz, 1Ph

Cooling

Capacity

Btu/h

8300

Input(standard rating)

W

935

Current(standard rating)

A

3.93

EER

W/W

2.61

Heating

Capacity

Btu/h

4400

Input

W

1350

Rated current

A

5.9

COP

W/W

N/A

Moisture Removal

L/h

1

Rated input consumption

W

1350

Rated current

A

5.9

Starting current

A

21.7

Plug type

0.75x3 / VDE

Control type

Remote Control

Compressor

Model

PA93M1C-4DZDE1

Type

ROTARY

Brand

GMCC

Refrigerant type

kg

R410A/0.35kg

Design pressure

MPa

4.2/1.5

Indoor fan motor

Model

YDK15-4(A)

Brand

Welling

Input

W

43/39/38

Capacitor

uF

1.5

Speed(hi/mi/lo)

r/min

1370/1230/1120

Evaporator

a.Number of rows

2

b.Tube pitch(a)x row pitch(b)

mm

21x13.37

c.Fin spacing

mm

1.3

d.Fin type (code)

Hydrophilic aluminium

e.Tube outside dia.and type

mm

Φ7,innergroove tube

f.Coil length x height x width

mm

322x210x26.74

g.Number of circuits

1

Indoor air flow (Hi/Mi/Lo)

m3/h

298

Indoor noise level (Hi/Mi/Lo)

dB(A)

56.5

Condenser

a.Number of rows

3

b.Tube pitch(a)x row pitch(b)

mm

19.5x11.6

c.Fin spacing

mm

1.2

d.Fin type (code)

UnHydrophilic aluminium

e.Tube outside dia.and type

mm

Φ5,innergroove tube

f.Coil length x height x width

mm

222x332x34.8

g.Number of circuits

2

 Outdoor  fan motor

Model

YDK62-4(B)

Brand

Welling

Input

W

110

Capacitor

uF

4.0

Speed(hi/mi/lo)

r/min

1150/--/--

Outdoor noise level (Hi/Mi/Lo) dB(A)

dB(A)

61.3

Dimension  (W*D*H)

mm

430x331x678

Packing  (W*D*H)

mm

492x402x840

Net/Gross weight

Kg

27.5/30.5

Operation temp (room temp.)

℃

17-35/5-30

Application area

m2

13-22

Qty’per 20’ /40’ /40'HQ

Pieces

128/268/402
